| Alinco has created a new 2 meter HT that sets new standards in features, convenience and easy operation. The DJ-195/196 sports an alphanumeric display for easy memory management. It has an ergonomic design that's 'user friendly' and the 5 watt output battery is standard. You'll be ready to travel the world with CTCSS encode+decode, DCS and European tone bursts, all included at no extra cost. Best of all, the DJ-195/196 retains the proud Alinco tradition of quality construction and excellent value.
Features:
- Alphanumeric display
- 40 memory channels
- 5 watt output with standard battery
- CTCSS encode+decode and DCS
- 13.8 VDC direct input with battery charge feature
- Direct frequency input
- S-meter
- Autodialer
- Cable Cloning
- Computer programmable (third party software required)
- MARS/CAP capability (DJ-195T/196T)
- Additional features, including theft alarm!
- Back-lit keypad (DJ-196T Only)
| Alphanumeric Display | Label channels in an easy-reading format. Display frequency, alpha label or channel number only. |
|---|
| 40 Memory Channels | Plenty of room to store your favorite simplex or repeater frequencies along with alphanumeric label, offset, CTCSS encode/decode or DCS setting. |
|---|
| 5 watts output | The standard battery allows the DJ-195/196 to produce up to 5 watts. A power input port
Accepts 13.8 VDC and charges the battery, but won't allow destructive overcharge. |
|---|
| CTCSS, DCS, Tone Bursts and DTMF | Be prepared for virtually any selective calling situation or gaining access to repeaters with protected inputs. European Tone Bursts include 1000, 1450, 1750 and 2100 Hz. |
|---|
| Direct Frequency Input | Frequency entry is easy using the well-spaced keypad. |
|---|
| S-Meter | Displays relative signal strength. |
|---|
| Cable Cloning | Share identical settings among multiple DJ-195/196 transceivers. Saves time and ensures uniform operation. |
|---|
| Removal Alarm | The DJ-195/196 can be set to emit a tone when disconnected from an external power source until proper action is taken to silence the alarm. |
|---|
| Experimental Insect Repel Feature | Can the DJ-195/196 actually repel mosquitoes? Activate the special tone and decide for yourself! You may find the DJ-195/196 can 'de-bug' your outdoor operating site! |
|---|
|
Specifications| General | | Freq. RX original status | 130 to 174 F2 F3 only |
|---|
| F2,F3,WFM |
|---|
| Freq. TX | F3 144-147.995 |
|---|
| Freq. Stability | +/-5ppm(-10 to +60c) |
|---|
| Antenna Imp. | 50 ohm unbalanced |
|---|
| Supply Voltage | DC 13.8V rated
DC 6.0min to 16V max |
|---|
| Ground | Negative GND |
|---|
| Current consumption | TX 5W 1.2A approx. |
|---|
| at 13.8V external source | RX 200mA approx/300mW
RX squelched 50mA approx.
RX Batt.Save on 20mA app. |
|---|
| Operating Temp. range | -10 to +60 degrees C. |
|---|
| Dimention w/o projection | 56(W) x 124(H) x 40 (D) |
|---|
| Weight with drycellcase+cell and antenna | N/a |
|---|
| Transmitter | | Output power | 5W 13.8V or EBP48N
Low=0.5W |
|---|
| Modulation | Variable reactance |
|---|
| Max. Deviation | n/a |
|---|
| Spurious emission | less than -60db |
|---|
| Microphone Imp. | 2k ohms approx. |
|---|
| Receiver | | Circuit | Double superheterodyne |
|---|
| 1st IF freq. | 21.7Mhz |
|---|
| 2nd IF freq. | 450khz |
|---|
| Sensitivity 12db SINAD | better than -8dbu (0.2uV or less) |
|---|
| Selectivity except WFM | more than -6db/12khz
less than -60db/28khz |
|---|
| Image/spurious response | less than -60db |
|---|
| AF out at 10% distort.13.8V | Max 300mW |
|---|
| AF impedance | 8 ohms |
|---|
| Standard feature | | Expandible RX range | none |
|---|
| MARS/CAP mod. | Yes |
|---|
| DTMF | tone encode |
|---|
| DCS SQ | enc/dec |
|---|
| CTCSS SQ | Enc/Dec 39tones |
|---|
| Memory ch. | 40ch non expandible |
|---|
| Auto Dialer memory | memory 9 memories, max 16 characters/memory |
|---|
| Call channel | Yes |
|---|
|
